Precision Floor Tile Making Machine Wet Cast Concrete Stone Veneer Production Line
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | HTX |
| Certification: | HTX-P-01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1Set |
|---|---|
| Price: | 15000-80000/USD |
| Packaging Details: | Normally carton box or following customer's requirements |
| Delivery Time: | 50Days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 500Sets/Month |
|
Detail Information |
|||
| Name: | Wet Cast Concrete Stone Veneer Production Line | Voltage: | 220V |
|---|---|---|---|
| Key Selling Points: | High Productivity | Capacity: | 800-1000m2 |
| Brick Type: | Concrete Dosing System | Weight: | 2000KG |
| Highlight: | Floor Tile Wet Cast Machinery,Wet Cast Stone Veneer Production Line,Precision Floor Tile Making Machine 220V |
||
Product Description
Precision Floor Tile Making Machine Wet Cast Concrete Stone Veneer Production Line
Product Description
wet cast concrete stone veneer production line is a manufacturing process that produces artificial stone veneers using wet-cast concrete technology. The production line typically consists of several machines and equipment that work together to produce high-quality stone veneers that resemble natural stone.
The wet cast concrete stone veneer production line typically includes the following steps:
1. Mixing: The raw materials, including cement, aggregates, pigments, and water, are mixed in a mixer to create a consistent and homogenous mixture.
2. Pouring: The mixture is then poured into molds that are designed to create the desired shape and texture of the stone veneer.
3. Compacting: The molds are then compacted using a vibrating table or other equipment to ensure that the mixture is evenly distributed and that any air pockets are eliminated.
4. Curing: The molded stones are then cured in a controlled environment, typically a humid and warm room, for a specific period of time to ensure that they have the required strength and durability.
5. Demolding: Once the stones have cured, they are removed from the molds and inspected for defects or imperfections.
Specifications
| Name | Model | Specification |
Size (mm) |
Power (Kw) |
Capacity (m2/day) |
Weight (Kg) |
|---|---|---|---|---|---|---|
| Artificial stone production line | HTX-P-01 |
Hydraulic driving;Auto feeding; vibrating and timing feeding |
7000*1000*1800 | 12.7 | 1000-1200 | 2000 |
| Artificial stone production line | HTX-P-01A | Full Auto,timing feeding and vibration, weighing system; | 12000*1000*2000 | 9.1 | 800-1000 | 2000 |
