Floor Tile Making Wet Casting Concrete Doser Machine Chemical Dosing Equipment
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | HTX |
| Certification: | HTX-P-01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1Set |
|---|---|
| Price: | 15000-80000/USD |
| Packaging Details: | Normally carton box or following customer's requirements |
| Delivery Time: | 50Days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 500Sets/Month |
|
Detail Information |
|||
| Name: | Factory Concrete Artificial Stone Production Line | Voltage: | 220V |
|---|---|---|---|
| Key Selling Points: | High Productivity | Capacity: | 800-1000m2 |
| Brick Type: | Concrete Dosing System | Weight: | 2000KG |
| Highlight: | Floor Tile Making Chemical Dosing Equipment,Wet Cast Concrete Doser,Chemical Wet Casting Concrete Doser Machine |
||
Product Description
Casting Concrete Doser Machine Chemical Dosing Equipment Floor Tile Making Machine
Product Description
A casting concrete doser machine is a specialized piece of equipment used in the production of precast concrete products, such as concrete panels, blocks, and slabs. The machine is designed to accurately measure and dispense the correct amount of concrete mixture into molds to ensure consistent and uniform product quality.The casting concrete doser machine typically includes the following components:Mixing system: A system of mixers that blend the cement, aggregates, pigments, and other additives together to create a homogeneous mixture.Dosing system: A system of dosers that accurately measure and dispense the correct amount of concrete mixture into molds. The dosing system can be customized to meet the specific needs of the project, including the size and shape of the molds and the desired product specifications.Molding system: A system of molds that are used to shape the concrete mixture into the desired product, such as wall panels, floor tiles, or concrete blocks.Curing system: A system of curing chambers or tunnels that provide the optimal temperature and humidity conditions for the products to cure and harden.
The casting concrete doser machine allows for the production of large volumes of precast concrete products quickly and efficiently, offering a cost-effective and sustainable alternative to traditional on-site concrete casting. The products produced by this machine offer several advantages over traditional concrete casting, including higher consistency, accuracy, and quality.
Applications
The feeding method is adjusted from horizontal unloading to bottom-up pumping and feeding. The feeding amount is more stable, and there will be no leakage or uneven feeding. A weighing system is added, and there is a weighing device under the discharge opening,which can weigh 5-25 kg of concrete, making the discharge volume more accurate.A digital display PLC control system is added, which is easy to operate and more intelligent.
Specifications
| Name | Model | Specification |
Size (mm) |
Power (Kw) |
Capacity (m2/day) |
Weight (Kg) |
|---|---|---|---|---|---|---|
| Artificial stone production line | HTX-P-01 |
Hydraulic driving;Auto feeding; vibrating and timing feeding |
7000*1000*1800 | 12.7 | 1000-1200 | 2000 |
| Artificial stone production line | HTX-P-01A | Full Auto,timing feeding and vibration, weighing system; | 12000*1000*2000 | 9.1 | 800-1000 | 2000 |
