Concrete Batching Plant Mix Wet Cast Machinery Artificial Stone Making Machine
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | HTX |
| Certification: | HTX-P-01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1Set |
|---|---|
| Price: | 15000-80000/USD |
| Packaging Details: | Normally carton box or following customer's requirements |
| Delivery Time: | 50Days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 500Sets/Month |
|
Detail Information |
|||
| Name: | Wet Cast Production Line | Voltage: | 220V |
|---|---|---|---|
| Key Selling Points: | High Productivity | Capacity: | 800-1000m2 |
| Brick Type: | Concrete Dosing System | Weight: | 2000KG |
| Highlight: | Concrete Batching Mix Wet Cast Machinery,Artificial Stone Making Wet Cast Machinery,Batch Systems Wet Cast Concrete Machinery |
||
Product Description
Wet Cast Mix Concrete Batching Plant Artificial Stone Making Machine
Product Description
wet cast concrete machinery is equipped with an automatic spraying system. The spraying system includes an air compressor, pneumatic air, and three rows of spray gun nozzles. The first row has 6 nozzles, which are used to spray air and remove dust on the mold. The 6 nozzles are controlled at the same time. need to be controlled individually. The second row of 2 spray guns is used for color spot spraying. The control system needs to be able to individually control the operation of each spray gun or simultaneously control the work and stop. The third row of three spray guns is used for full spraying. It needs to control 6 nozzles at the same time and does not need to be controlled separately. If there is no need to spray color, the second row and the third row are used to spray release oil.
Wet concrete dosing system, is suitable for different silicone molds, rubber molds and plastic molds, size range from 200*200mm to 1500*1500mm, available for producing the artificial stone both for wall and floor paving, 3D Wall panel, terrazzo floor tile, etc .
Applications
Concrete casting wet doser machine Product Details :More efficient production, can achieve 800M2 Per day (8hrs),Multiple function for production, it include unloading, painting, concrete dosing and stacking, and available usage for plastic molds of floor tile and terrazzo tile, silicone molds for artificial stone etc.Labors saving for production, 5-6 workers needed only, can largely reduce the labor cost of factory output.
Specifications
| Name | Model | Specification |
Size (mm) |
Power (Kw) |
Capacity (m2/day) |
Weight (Kg) |
|---|---|---|---|---|---|---|
| Artificial stone production line | HTX-P-01 |
Hydraulic driving;Auto feeding; vibrating and timing feeding |
7000*1000*1800 | 12.7 | 1000-1200 | 2000 |
| Artificial stone production line | HTX-P-01A | Full Auto,timing feeding and vibration, weighing system; | 12000*1000*2000 | 9.1 | 800-1000 | 2000 |
