Exterior Faux Stone Panels Wet Cast Machinery Auto Out Demoulding
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | HTX |
| Certification: | HTX-P-01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1Set |
|---|---|
| Price: | 15000-80000/USD |
| Packaging Details: | Normally carton box or following customer's requirements |
| Delivery Time: | 50Days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 500Sets/Month |
|
Detail Information |
|||
| Name: | Factory Concrete Artificial Stone Production Line | Voltage: | 220V |
|---|---|---|---|
| Key Selling Points: | High Productivity | Capacity: | 800-1000m2 |
| Brick Type: | Concrete Dosing System | Weight: | 2000KG |
| Highlight: | Auto Out Demoulding Wet Cast Machinery,Faux Stone Panels Concrete Dosing System,1000m2 Wet Cast Machinery |
||
Product Description
Auto Out Demoulding Exterior Faux Stone Panels Wet Cast Machinery
Product Description
wet cast concrete machinery production of paver tile molds, we also provide customers with a variety of production line solutions for the production process of finished paver tiles.One of the solutions is single dosing production line + concrete mixer + PLC control cabinet.Single Dosing machine: Size: 9000*1000*2000mm, 10.7kw, the machine is controlled by a time relay, timing vibration, timing feeding, weighing control; Automatic concrete mixer: size: 2200*1800*2000mm, 25.6kw, the machine is automatic water supply, automatic mixing, automatic unloading;Control cabinet PLC: Both 12v&220v, size: 600*800*50mm; touch screen, weighing adjustment and time control.
Applications
The feeding method is adjusted from horizontal unloading to bottom-up pumping and feeding. The feeding amount is more stable, and there will be no leakage or uneven feeding. A weighing system is added, and there is a weighing device under the discharge opening,which can weigh 5-25 kg of concrete, making the discharge volume more accurate.A digital display PLC control system is added, which is easy to operate and more intelligent.
Specifications
| Name | Model | Specification |
Size (mm) |
Power (Kw) |
Capacity (m2/day) |
Weight (Kg) |
|---|---|---|---|---|---|---|
| Artificial stone production line | HTX-P-01 |
Hydraulic driving;Auto feeding; vibrating and timing feeding |
7000*1000*1800 | 12.7 | 1000-1200 | 2000 |
| Artificial stone production line | HTX-P-01A | Full Auto,timing feeding and vibration, weighing system; | 12000*1000*2000 | 9.1 | 800-1000 | 2000 |
