Concrete Dosing System Wet Cast Machinery 3d Faux Brick Wall Panels Production Line
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | HTX |
| Certification: | HTX-P-01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1Set |
|---|---|
| Price: | 15000-80000/USD |
| Packaging Details: | Normally carton box or following customer's requirements |
| Delivery Time: | 50Days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 500Sets/Month |
|
Detail Information |
|||
| Name: | Concrete Wet Cast Machine | Voltage: | 220V |
|---|---|---|---|
| Key Selling Points: | High Productivity | Capacity: | 800-1000m2 |
| Brick Type: | Concrete Dosing System | Weight: | 2000KG |
| Highlight: | Faux Brick Panels Concrete Dosing System,3d Wall Panel Wet Cast Machinery,Concrete Dosing System Wet Cast Machinery |
||
Product Description
Concrete Dosing System 3d Faux Brick Wall Panels Production Line
Product Description
wet cast concrete machinery uses single-silo ingredients. Your cement can be directly transferred to the mold through the silo, and conveyed through the transmission belt to improve production efficiency. The daily production output is 500-600 square meters, which is completely impossible for manual production lines.The length of the entire production line is 8 meters, which can be expanded to 15 meters according to demand, requiring a workshop space of 300-400 square meters; it has the functions of timing cutting, timing vibration, and fixed-point transmission.
Specifications
| Name | Model | Specification |
Size (mm) |
Power (Kw) |
Capacity (m2/day) |
Weight (Kg) |
|---|---|---|---|---|---|---|
| Wet Cast Machinery | HTX-P-01 |
Hydraulic driving;Auto feeding; vibrating and timing feeding |
7000*1000*1800 | 12.7 | 1000-1200 | 2000 |
| Artificial stone production line | HTX-P-01A | Full Auto,timing feeding and vibration, weighing system; | 12000*1000*2000 | 9.1 | 800-1000 | 2000 |
Applications
Specializing in the manufacture of fully automatic Wet Cast Equipment for more than ten years, which can be customized according to customer requirements(the size of the factory, size of the molds and shape of the molds), it is suitable for all kinds of precast concrete molds of different quality,different specifications and different shapes of cultural stone, wall and floor paving, 3D Wall panel, terrazzo floor tile, etc .From formulated raw materials to demoulding and packaging. All can be automated, save time and effort.
Feature advantage
In order to improve the production rate, we designed two types of artificial stone production line. They are semi auto production line and full auto production line. It not only improve the production efficiency but also lower the labour quantity and cost. It will be a good choice for artificial stone producing.
We offer more than 300 coloring ingredient technical support, train your worker from the start to the end for artificial stone coloring process, this will help you make this business much easier.
