Labor Saving Automatic Wall Panel Concrete Dosing System Floor Tile Making Machine
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | HTX |
| Certification: | ISO9001 |
| Model Number: | HTX-P-01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1Set |
|---|---|
| Price: | 15000-80000/USD |
| Packaging Details: | Normally carton box or following customer's requirements |
| Delivery Time: | 50Days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 500Sets/Month |
|
Detail Information |
|||
| Name: | Artificial Stone Production Line | Size: | 1500*1300*2500cm |
|---|---|---|---|
| Weight: | 2000kg | Color: | Blue |
| Advantage: | Easy Operation | ||
| Highlight: | Labor Saving Concrete Dosing System,Concrete Dosing Wall Panel Making Machine,Floor Tile Concrete Dosing System |
||
Product Description
Labor Saving Automatic Wall Panel Concrete Dosing System Floor Tile Making Machine
Product Description
A wall panel concrete dosing system is a specialized piece of equipment used in the production of precast concrete wall panels. The system is designed to accurately dose and mix the components of the concrete mixture, including cement, aggregates, water, and additives, in the correct proportions to achieve the desired properties and quality of the finished wall panels.
The dosing system typically consists of several components, including:
1.Cement silos: Large storage containers that hold cement and other cementitious materials.
2.Aggregate storage bins: Containers that hold aggregates, such as sand, gravel, and crushed stone.
3.Weighing system: A system of scales that accurately measures the amount of each component to be used in the concrete mixture.
4.Mixing system: A system of mixers that blend the components together to create a homogeneous mixture.
5.Control system: A computerized system that controls the dosing and mixing processes to ensure consistency and quality.
The wall panel concrete dosing system is typically used in a precast concrete production facility, where wall panels are manufactured in a controlled environment. The system can be customized to meet the specific needs of the project, including the size and shape of the wall panels, the required strength and durability, and the desired surface finish.Overall, the wall panel concrete dosing system plays a crucial role in ensuring the quality and consistency of precast concrete wall panels, which are widely used in the construction industry for their speed, efficiency, and durability.
Specifications
| Name | Model | Specification |
Size (mm) |
Power (Kw) |
Capacity (m2/day) |
Weight (Kg) |
| Artificial stone production line | HTX-P-01 |
Hydraulic driving;Auto feeding; vibrating and timing feeding |
7000*1000*1800 | 12.7 | 800-1000 | 2000 |
| Artificial stone production line | HTX-P-02 | Chain drived;Auto feeding,auto vibration | 8000*1100*1600 | 4.05 | 600-800 | 1500 |
